- Full Power at Wide Output Current Range (Constant Power)
- Adjustable Output Current (AOC) with NFC
- DALI-2 and D4i Certified
- 3-Timer-Modes Dimmable
- Dim-to-Off with Standby Power ≤ 0.5W
- Dimming range: 5%-100%
- Always-on Auxiliary Power: 24Vdc,125mA,3W (Transient
- ak Power up to 10W)
- Integrated 16Vdc Bus Power Supply based on DALI-2
- Integrated Power Monitoring with High Accuracy up to ±1%
- Low Inrush Current
- Output Lumen Compensation
- End-of-Life Indicator
- Thermal Sensing and Protection for LED Module
- Input Surge Protection: DM 6kV, CM 10kV
- All-Around Protection: IUVP, IOVP, OVP, SCP, OTP
- IP66/IP67 and UL Dry/Damp/Wet Location
- TYPE HL, for use in a Class I, Division 2 Hazardous
(Classified) Location - 7 Year Warranty
Life Time
110,000 hours @ Case Temperature 70°C
Dimensions
Inches (L x W x H)
10.31 × 3.54 × 1.71
Millimeters (L x W x H)
262 × 90 × 43.5
Certifications
| Full-Power Current Range | Default Output Current | Input Voltage Range | Output Voltage Range | Max. Output Power | Model Number |
|---|---|---|---|---|---|
| 1050 – 1400 mA | 1.4 A | 90 – 305 Vac 127 – 300 Vdc |
171 – 457 Vdc | 480 W | EUM-480S140BG |
| 2100 – 2800 mA | 2.8 A | 86 – 228 Vdc | EUM-480S280BG | ||
| 3150 – 4200 mA | 4.2 A | 57 – 152 Vdc | EUM-480S420BG | ||
| 4350 – 5600 mA | 5.6 A | 43 – 110 Vdc | EUM-480S560BG | ||
| 8600 – 10000 mA | 10 A | 24 – 56 Vdc | EUM-480S10ABG |
|
