- Compact metal case with excellent thermal performance
- Full power at wide output current range (constant power)
- Adjustable output current (AOC) with T4T (Tuner4TRONIC)
- Isolated 1(0)-5V / 1(0)-10V / PWM / Resistor / AstroDIM (Timer) dimmable
- Dim-to-Off with standby power ≤ 0.5 W
- Adjustable dimming curve
- Always-on auxiliary power: 12Vdc, 100mA on specific models
- End-of-life indicator
- Override dimming
- Constant lumen
- Input surge protection: DM 6kV, CM 10kV
- All-around protection: OTP, OVP, SCP
- 5 Year Warranty
Life Time
117,000 hours @ Case Temperature 70°C
Dimensions
Inches (L x W x H)
6.34 x 2.36 x 1.31
Millimeters (L x W x H)
161 x 60 x 33.4
Certifications
Adjustable Output Current Range (mA) | Full Power Current Range (mA) | Default Output Current (mA) | Nominal Output Voltage Range (Vdc) | Maximum Output Power (W) | Typical Efficiency | Power Factor λ | Product Name | |
---|---|---|---|---|---|---|---|---|
– | 120Vac | 230Vac | – | |||||
70–1050 | 700–1050 | 700 | 72–214 | 150 | 94.0% | 0.99 | 0.96 | IT 0-10 150/100-277/1A05 P67 y |
268–4200 | 2680–4200 | 3150 | 18–56 | 150 | 92.5% | 0.99 | 0.96 | IT 0-10 150/100-277/4A2 P67 y |
File Name
|
---|
LED Driver Installation Instructions
|
Programming Interface Device Driver Install First (Updated March 2015)
|
Design-in Guide for Programming Drivers (Updated September 2018)
|
